HydroTap G5 Classic Plus boiling chilled sparkling 240/175

Confirm Purchase


Do you own an uninstalled HydroTap?

Yes No

Confirm Purchase


Please purchase a HydroTap first

Ok

Click to Zoom

Request A Quote
Finish

View our range of finishes for this product.

This product is not available for online sale. Please contact Zip for more information.

Boiling
Chilled
Sparkling
Filtered
H55763Z00UK

Get instant filtered boiling, chilled and sparkling drinking water tap for your office or workplace with the Zip Water HydroTap Classic Plus in bright chrome.

Manufacturing Code
H55763Z00UK
Capacity
Commercial
Number of people
100
Boiling Cups per hour
240
Chilled Cups per hour
175
Combined Chilled and Sparkling Cups per hour
175

Product Details

The world's most advanced drinking water system, the HydroTap Classic Plus delivers a choice of instant filtered boiling, chilled and sparkling water for workplaces of all sizes. From a single tap and under counter command centre, the Classic Plus dispenses only the purest tasting water, filtered to a market-leading 0.2 micron - 25 times more effective than a standard water filter jug. To prioritise user safety, the HydroTap doesn't splash or spit when dispensing water, and features two boiling water safety modes and a cool to touch tap. What's more, the HydroTap features superior technology to conserve water while saving energy and time.

Specifications

Tap
HydroTap Classic Plus bright chrome
Water Pressure
Min 2.5 bar - Max 5 bar
Water Connection
1/2" BSP
Water Supply Requirements
Cold
Water Valves
Integrated dual check valve
Power Rating
2.3kW 230v 50/60 Hz
Booster Power Rating
Zip HydroTap booster 2.2kW at 230V
Power Supply
2 x 13 amp
Dimensions
W500 x D520 x H373
Product Approvals
CE, UKCA
Warranty
Appliance warranty 24 months plus additional 36 months boiling tank warranty

Manuals

  • Quick Guide
  • Instruction Manual
  • User Manual

Installation

Installation Requirements

1. Installation and connection of your Zip HydroTap must be carried out by a qualified person, observing national and local regulations.
2. You will require suitable mains electrical and drinking water connections, plus waste water drainage all within 1 metre of the product.
3. HydroTap is air-cooled so discrete cabinetry cut-outs are required for ventilation.
4. Installation on most bench tops is straightforward however some stone bench tops may require a specialised cutting service.
5. If you live in a hard water area, we recommend the installation of a Zip limescale filtration kit.
6. Installation by our HydroCare team can be arranged with a phone call or through www.zipwater.co.uk

Certifications

CE Image
UKCA Mark

BIM Files

  • ArchiCAD Zip Water Library
  • AutoCAD Plan
  • Revit Product File
  • Revit Virtual Showroom Project File
  • IFC
